Comparing Front-Loading vs Top-Loading Kilns

When choosing a kiln, one important consideration is how you will load and unload it. Electric kilns are generally designed as either front-loading or top-loading. There are a few differences between the two styles. You can find more information on each style below.

Ease of use

Front-loading kilns are generally easier to load since they have a side-hinged door. This allows you to slide the pieces in rather than lowering them into the kiln chamber like you would on a top-loading kiln. This gives them an advantage for those with back or shoulder issues and those who fire large or uniquely shaped pieces or larger amounts of work.

For these same reasons, a top-loading kiln can be more difficult to load, especially if you select a kiln with a deeper chamber.

Studio Space

Front-loading kilns take up more space in your studio since the door hinges outwards. You will have to account for the length of the door plus a few feet of space in front of your kiln for it to open fully and the kiln operator to work comfortably.

For example, if the kiln is around 4 feet wide, you’ll want 7 feet of space in front of the kiln: around 4 feet for the door and around 3 feet for the kiln operator.

So, if you are running low on space, top-loading kilns are the way to go. Since the door opens upward, you won’t have to allow for the same clearance a front-loading kiln needs.

Maintenance

Heating elements will wear out over time, so maintenance is a necessary consideration when deciding between the two kiln styles. Front-loading heating elements can be more difficult to access. Since the chamber is oriented horizontally, elements in the back can be hard to reach.

Heating elements in top-loading kilns are typically easier to replace because they’re accessible from above and they come in sectional models. If you have a sectional model, the kiln’s rings can also be separated and reassembled, making it even easier as it allows you to work on one section at a time.

Choosing the right kiln

After comparing these differences you should be able to determine which style is right for you and your studio. If this is your first kiln purchase, check out our guide on How to Select the Electric Kiln That’s Right for You.
